IK PSU 9175 (iRig PSU 9175)
Power supply unit for: AXE I/O iRig Micro Amp iRig Pro Duo iRig Pro Duo I/O iRig Pro...
iRig Pro Duo I/O
Make the world your studio
2-channel audio and MIDI interface for iPhone, iPad and Mac/PC
$229.99($280.59 incl. VAT)
2-in/2-out audio and MIDI interface
Works with iPhone, iPad, Mac and PC
Combo XLR/TRS inputs with phantom power
MIDI In/Out
24-bit/48 kHz
Battery or bus powered
Works with iPhone, iPad, Mac and PC
Combo XLR/TRS inputs with phantom power
MIDI In/Out
24-bit/48 kHz
Battery or bus powered
See Specs
iRig Pro Duo I/O Specifications
Microphone Input
Microphone Input: 2x balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
Microphone Input Level: from 6 mVpp to 1.4 Vpp
Microphone Input Impedance: 3,2 kOhms
Gain Range: 50 dB
Phantom Power: +48V ± 4V
Frequency Response: 20 Hz to 20 kHz (+-1.5dB)
Input Noise: -103 dB(A), -97 dB RMS
Instrument Input
Instrument Input: 2x unbalanced, Hi-Z, TS 1/4” Jack, Tip: signal / Shield: ground
Instrument Input Level: from 30 mVpp to 6.9 Vpp
Instrument Input Impedance: 1 MOhms
Gain Range: 27 dB
Frequency Response: from 2 Hz to 21 kHz (-3dB) Gain @ min; from 5 Hz to 21 kHz (-3dB) Gain @ max
Input Noise: -104 dB(A) Gain @ min; -102 dB(A) Gain @ max
Line Output
Line Outputs: 2x balanced, TRS 1/4” Jack, Tip: hot / Ring: cold / Shield: ground
Floating Balanced Outputs with automatic level compensation when working in unbalanced mode
Maximum Output Level: +16 dBu into 600 Ohms balanced load
Frequency Response: from 10 Hz to 21 kHz (-3dB)
Output Dynamic Range: 106 dB(A)
Output Impedance: 150 Ohms balanced
Common
AD and DA Resolution: 24-bit
Sampling Rate: 44.1 kHz and 48 kHz
Power: USB bus power, battery power (2xAA - included), or DC power supply (9VDC, from 500mA up, positive outside - not included)
Metering: Multicolor LED
Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
Weight: 197.2g/6.96oz (batteries excluded)
Battery Life: Recording - Max load*: 3 hours, 30 minutes (NiMH rechargeable); 45 minutes (Alkaline). Playback - Min load**: 10 hours (NiMH rechargeable); 3 hours (Alkaline)
*Max load condition: both inputs connected to two 1,5mA phantom powered loads, input gains set to maximum, outputs set to maximum.
**Min load condition is as follows: music playing, phantom power OFF.
Package includes
iRig Pro Duo universal dual channel Audio-MIDI interface
Lightning to Mini-DIN connection cable (60cm/23.62")
USB-C to Mini-DIN connection cable (60cm/23.62")
USB to Mini-DIN connection cable (60cm/23.62")
2x 2.5mm TRS male to MIDI female adapter (10cm/3.9")
2 x 1.5V AA Battery
Dimensions
Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
Weight: 197.2g/6.96oz (batteries excluded)
Compatibility
iOS Devices
Made for: iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPad Pro 10.5-inch, iPad Pro 12.9-inch (2nd generation), iPad Pro 9.7-inch, iPad Pro 12.9-inch (1st generation), iPad Air 2, iPad Air, iPad mini 4, iPad mini 3, iPad mini 2, iPad (6th generation), iPad (5th generation), iPod touch (6th generation).
Also compatible with all newer iPhone, iPad and iPod touch models.
Computers
Mac®: Mac OS X 10.6 or later. One free USB port.
Windows®: One free USB port. For low latency, the IK Multimedia's iRig audio driver must be installed.
Android Devices
Compatible with Android devices running Android 5 or later and with USB digital audio capabilities.
Click to zoom · Esc to close
Make the world your studio
iRig Pro Duo I/O is a portable 2-in/2-out audio and MIDI interface for recording music, podcasts, video and live streams wherever you go.
Two combo XLR/TRS inputs with Class-A preamps let you connect microphones, guitars, basses and line-level sources, with +48 V phantom power for condenser mics. Balanced outputs, headphone monitoring, direct monitoring and MIDI In/Out provide the connections for a complete mobile setup, while battery, bus or optional DC power keeps you ready to record with iPhone, iPad, Android, Mac or PC.
Get started
Here's how to register your product and download your Free Bonus Content and manuals.
-
Create your IK Multimedia account
If you're not an IK registered user yet, create your IK Multimedia account. Already have one? Skip this step.
-
Register and authorize your product
Download and install the IK Multimedia Product Manager, the standalone app for registration, downloads, installation, authorization, updates, user manuals and Free Bonus Content. Already installed? Skip the download.
Run the Product Manager and click Register to register and authorize your product. Once it's registered, the Product Manager lists all your Free Bonus Content, ready to download and authorize.
Specs
iRig Pro Duo I/O Specifications
Microphone Input
Microphone Input: 2x balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
Microphone Input Level: from 6 mVpp to 1.4 Vpp
Microphone Input Impedance: 3,2 kOhms
Gain Range: 50 dB
Phantom Power: +48V ± 4V
Frequency Response: 20 Hz to 20 kHz (+-1.5dB)
Input Noise: -103 dB(A), -97 dB RMS
Instrument Input
Instrument Input: 2x unbalanced, Hi-Z, TS 1/4” Jack, Tip: signal / Shield: ground
Instrument Input Level: from 30 mVpp to 6.9 Vpp
Instrument Input Impedance: 1 MOhms
Gain Range: 27 dB
Frequency Response: from 2 Hz to 21 kHz (-3dB) Gain @ min; from 5 Hz to 21 kHz (-3dB) Gain @ max
Input Noise: -104 dB(A) Gain @ min; -102 dB(A) Gain @ max
Line Output
Line Outputs: 2x balanced, TRS 1/4” Jack, Tip: hot / Ring: cold / Shield: ground
Floating Balanced Outputs with automatic level compensation when working in unbalanced mode
Maximum Output Level: +16 dBu into 600 Ohms balanced load
Frequency Response: from 10 Hz to 21 kHz (-3dB)
Output Dynamic Range: 106 dB(A)
Output Impedance: 150 Ohms balanced
Common
AD and DA Resolution: 24-bit
Sampling Rate: 44.1 kHz and 48 kHz
Power: USB bus power, battery power (2xAA - included), or DC power supply (9VDC, from 500mA up, positive outside - not included)
Metering: Multicolor LED
Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
Weight: 197.2g/6.96oz (batteries excluded)
Battery Life: Recording - Max load*: 3 hours, 30 minutes (NiMH rechargeable); 45 minutes (Alkaline). Playback - Min load**: 10 hours (NiMH rechargeable); 3 hours (Alkaline)
*Max load condition: both inputs connected to two 1,5mA phantom powered loads, input gains set to maximum, outputs set to maximum.
**Min load condition is as follows: music playing, phantom power OFF.
Package includes
iRig Pro Duo universal dual channel Audio-MIDI interface
Lightning to Mini-DIN connection cable (60cm/23.62")
USB-C to Mini-DIN connection cable (60cm/23.62")
USB to Mini-DIN connection cable (60cm/23.62")
2x 2.5mm TRS male to MIDI female adapter (10cm/3.9")
2 x 1.5V AA Battery
Dimensions
Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
Weight: 197.2g/6.96oz (batteries excluded)
Compatibility
iOS Devices
Made for: iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPad Pro 10.5-inch, iPad Pro 12.9-inch (2nd generation), iPad Pro 9.7-inch, iPad Pro 12.9-inch (1st generation), iPad Air 2, iPad Air, iPad mini 4, iPad mini 3, iPad mini 2, iPad (6th generation), iPad (5th generation), iPod touch (6th generation).
Also compatible with all newer iPhone, iPad and iPod touch models.
Computers
Mac®: Mac OS X 10.6 or later. One free USB port.
Windows®: One free USB port. For low latency, the IK Multimedia's iRig audio driver must be installed.
Android Devices
Compatible with Android devices running Android 5 or later and with USB digital audio capabilities.
